Compare
the pathological image-left and the physiological image-right
(blinded)
<<
F:
Marked
dilation of the major bronchi with mucous
and irregular wall (bronchial wall thickening).
H:
Adult
woman, 22-years old, suffers from cystic fibrosis, now repeated cough, fever
and dyspnoe
INFO/WWW-LINKS:
The most severe affected systems in cystic fibrosis are the respiratory, hepatobilary
and the reproductive tract. Abnormal mucous plugging of the bronchi leads
to obstruction. That causes bronchial dilatation (bronchiectasis)
and infections, which may result in the formation of cavities.
D:
Severe
bronchiectasis in cystic fibrosis
IN
THIS PART OF THE PAGE YOU FIND SOME TEXT FIELDS WHICH CAN BE OPENED EIGTHER
STEP BY STEP (CLICK ON "HISTORY", "HELP", "FINDINGS",
"DIAGNOSIS" OR "INFO/WWW-LINKS") OR AT ONCE WITH A CLICK
ON "ALL ON" - VICE VERSA CLICK ON "ALL OFF".
If you need a physiological
image to compare click here
