Compare
the pathological image-left and the physiological image-right
(blinded)
<<
F:
there
is a thick walled cavity in the left apical and posterior segments of the upper
lobe with surrounding consolidation
H:
Adult
man, 81-years-old, cough, fever, night sweats, haemoptysis, diabetes mellitus,
alcohol abus
INFO/WWW-LINKS:
Any form of immuncompromise may cause a post-primary TB: e.g. malignancy,
diabetes mellitus, treatment with steroids, HIV and in elderly patients. In
cavitating TB (one
form of post-primary TB) you may find fibrocavitary apical disease and pneumonic
infiltrates
D:
cavitating
tuberculous infection in the left upper lobe, with surrounding consolidation
and pneumonic infiltrates
IN
THIS PART OF THE PAGE YOU FIND SOME TEXT FIELDS WHICH CAN BE OPENED EIGTHER
STEP BY STEP (CLICK ON "HISTORY", "HELP", "FINDINGS",
"DIAGNOSIS" OR "INFO/WWW-LINKS") OR AT ONCE WITH A CLICK
ON "ALL ON" - VICE VERSA CLICK ON "ALL OFF".
If you need a physiological
image to compare click here
