Compare
the pathological image-left and the physiological image-right
(blinded)
<<
F:
Filling
defect
of
the superior mesenteric artery. But another finding is a hypodens lesion
in segment 6 of the liver
H:
Adult
man, 47-years-old, with atrial fibrilation, admitted with acute abdomen.
INFO/WWW-LINKS:
Acute embolism may occure after myocardial infarction caused by mobilized
mural thrombus or other cardiac disease (e.g. diseased valves). Other causes
are atrial fibrillation, polycythaemia and left atrial myxomas. Problems associated
with prosthetic valves are thrombosis (especially at the mitral position),
paravalvular leaks, endocarditis and degenerative changes in tissue valves.
Congenital cysts of the
liver are often combined with other cystic disorders, e.g. pancreatic
cysts and/or renal cysts. Most common kind of congenital cysts are solitary
cysts - shown in the image above. These cysts may increase in size and may
cause portal hypertension.
D:
Acute embolism
of the superior mesenteric artery and a congenital cyst of the liver.
IN
THIS PART OF THE PAGE YOU FIND SOME TEXT FIELDS WHICH CAN BE OPENED EIGTHER
STEP BY STEP (CLICK ON "HISTORY", "HELP", "FINDINGS",
"DIAGNOSIS" OR "INFO/WWW-LINKS") OR AT ONCE WITH A CLICK
ON "ALL ON" - VICE VERSA CLICK ON "ALL OFF".
It is not
easy to find an exactly corresponding slice to every pathological example!
For that reason the
FILM
(2)
is
recommended!
Once opened you may use it for every pathological example.
If you need a physiological
image to compare click here
